5 ways to update zfs on archlinux

introduction

tl;dr check out this repo jbrodriguez/arch-zfs-docker: docker to build zfs-linux-lts & zfs-utils

i have an archlinux server that i use for general purposes (photoview is one of them), with zfs based storage (i have discussed zfs previously here and here)

i generally update archlinux once a month, but since zfs is not built-in into the kernel, there are times when zfs gets behind newer kernels

additionally, archzfs, which builds zfs for archlinux can sometimes get behind zfs/openzfs

i mitigated this by switching to an lts kernel (linux-lts) and while this helps, i still found myself in a situation where i can’t do a full system upgrade due to zfs

there are some potential solutions to this, let’s take a look

the archzfs way

this is the sanctioned way

the archlinux wiki describes all the steps required to use the archzfs repo to install/upgrade zfs

cons

• it can get behind openzfs, which can get behind kernels
• build bot can be down or builds can be failing

inversion of control (technically not a zfs update)

what if, instead of looking for a zfs-linux-lts to match a new kernel, we go the other way ?

there is a kernel repo that answers the question: is there a matching kernel for my current version of zfs ?

this is all described here https://end.re/blog/ebp036_archzfs-repo-for-kernels/#update-on-2020-12-17

cons

• it’s highly likely that you will remain on an “older” linux-lts version

the devtools of summer

so you can build zfs-linux-lts on your own, by installing the appropriate packages on your system: base-devel and devtools will allow you to build and install zfs-linux-lts

i did this on a fresh archlinux install and it worked like a charm

i have to thank hoban, since his instructions were the base for getting this done

as a shortcut, here are the steps:

❯ git clone https://aur.archlinux.org/zfs-linux-lts.git

❯ vim PKGBUILD
# <interactive output omitted, see diff below>

❯ git --no-pager diff
diff --git a/PKGBUILD b/PKGBUILD
index aad1ea7..71fdbb3 100644
--- a/PKGBUILD
+++ b/PKGBUILD
@@ -18,9 +18,9 @@
 pkgbase="zfs-linux-lts"
 pkgname=("zfs-linux-lts" "zfs-linux-lts-headers")
 _zfsver="2.2.2"
-_kernelver="6.1.66-1"
-_kernelver_full="6.1.66-1"
-_extramodules="6.1.66-1-lts"
+_kernelver="6.1.68-1"
+_kernelver_full="6.1.68-1"
+_extramodules="6.1.68-1-lts"

 pkgver="${_zfsver}_$(echo ${_kernelver} | sed s/-/./g)"
 pkgrel=1

❯ makepkg -scir
# <package building output omitted>

❯ ls
PKGBUILD  zfs-2.2.2.tar.gz  zfs.install  zfs-linux-lts-2.2.2_6.1.68.1-1-x86_64.pkg.tar.zst  zfs-linux-lts-headers-2.2.2_6.1.68.1-1-x86_64.pkg.tar.zst

❯ pacman -Q | grep 6.1.68
linux-lts 6.1.68-1
linux-lts-headers 6.1.68-1
zfs-linux-lts 2.2.2_6.1.68.1-1
zfs-linux-lts-headers 2.2.2_6.1.68.1-1

❯ uname -r
6.1.68-1-lts
# <the above was post-reboot>

the big issue with this … it didn’t work once a new kernel was released

since, the build process looks at the packages in your system, it detects an old version of the kernel and you can’t move forward

cons

• you have to install base-devel and devtools in your system, which increases the exposed surface area of your server, the less packages you have on a server the better
• it will outright not work when there’s a new kernel and you are building on the same system you are running

one archroot to rule them all

the next best thing is to create an archroot on your system, so you can install a fresh linux kernel on the archroot, then build/install any package you want, in my case, just build

this is a great solution, you don’t depend on the kernel version on your system, so you can build the latest kernel + zfs version that supports that kernel (awesome)

in general terms, these are the steps

mkarchroot "~/chroot/root" linux-lts zfs-utils base-devel
cd ~/chroot
git clone https://aur.archlinux.org/zfs-linux-lts.git
cd zfs-linux-lts
makechrootpkg -c -u -r ~/chroot/root

cons

• the same caveat as before: you still need to install devtools in your system

docker for the win

”it’s the eyes, chico” … i mean, it’s the dockers, it’s always been the dockers :)

i can finally rest

UPDATE 2024-08-07: i created a github repo with the Dockerfile and script, with a simplified build process

i just created a Dockerfile from archlinux:base-devel, added some packages (no archroot needed), to create a fresh zfs-linux-lts, based on the corresponding linux-lts, all in a very automated way

this is the Dockerfile

FROM archlinux:base-devel

RUN useradd -m build && \
    pacman -Syu --noconfirm && \
    pacman -Sy --noconfirm git linux-lts && \
    # Allow build to run stuff as root (to install dependencies):
    echo "build ALL=(ALL) NOPASSWD: ALL" > /etc/sudoers.d/build

RUN echo -e "\n[archzfs]\nServer = https://archzfs.com/\$repo/\$arch" >> /etc/pacman.conf && \
    pacman-key -r DDF7DB817396A49B2A2723F7403BD972F75D9D76 && \
    pacman-key --init && \
    pacman-key --lsign-key DDF7DB817396A49B2A2723F7403BD972F75D9D76 && \
    pacman -Syu --noconfirm && \
    pacman --sync --noconfirm --noprogressbar --quiet zfs-utils

# Continue execution (and CMD) as build:
USER build
WORKDIR /home/build

# Build the package
WORKDIR /package

USER root

COPY ./update_pkgbuild.sh /usr/local/bin/update_pkgbuild.sh

RUN chmod +x /usr/local/bin/update_pkgbuild.sh
USER build

# Clone the repository, update PKGBUILD, and build package
CMD git clone https://aur.archlinux.org/zfs-linux-lts.git . && \
    /usr/local/bin/update_pkgbuild.sh && \
    makepkg --syncdeps --clean --rmdeps --noconfirm

and this is the update_pkgbuild.sh script

#!/bin/bash

lts_version=$(pacman -Qe | grep "^linux-lts" | awk '{print $2}')
if [ -z "$lts_version" ]; then
    echo "Error: linux-lts version not found"
    exit 1
fi

full_kernel_version=$lts_version

sed -i \
    -e "s/^_kernelver=.*/_kernelver=\"$full_kernel_version\"/" \
    -e "s/^*kernelver*full=.*/*kernelver*full=\"$full_kernel_version\"/" \
    -e "s/^_extramodules=.*/_extramodules=\"$full_kernel_version-lts\"/" \
    PKGBUILD

echo "PKGBUILD updated with linux-lts version $full_kernel_version"

the cherry on top:

create a custom local repository, so you can just invoke pacman -Syu and it will pickup the zfs-linux-lts you just built

bonus round & final thoughts

there’s another way to update zfs, described here

the main driver for this article are these 2 github issues

• why are you providing zfs 2.2.4 for kernel 6.9.x? · Issue #538 · archzfs/archzfs
• ci.archzfs.com down · Issue #540 · archzfs/archzfs

comment about the article here

i found myself unable to upgrade my archlinux system due to zfs falling behind newer kernels
